- robust construction
- low vibration running
- CE compliant
After logging in, the trade prices are visible.
Delivery time 2-5 days
Productnumber:
710315-1_grey
Description
The professionally designed surface belt grinders of the BS series are characterized by a robust design and user-friendly handling. The quick and easy sanding belt change enables economical use in industry, in the trade and by private professional craftsmen.
The surface belt grinder with built-in wet sanding device is manufactured with a reinforced drive motor. The large water catch tray effectively collects the coolant and still allows unrestricted work on the machine. A top filter on the coolant tank effectively retains the abrasive and impurities, thus guaranteeing a long coolant service life.
• Economical sanding due to simple and quick belt changes
• Perfect safety by means of belt protection box made of sheet steel or aluminum
• Available in various designs and belt widths to suit your needs
The surface belt grinder with built-in wet sanding device is manufactured with a reinforced drive motor. The large water catch tray effectively collects the coolant and still allows unrestricted work on the machine. A top filter on the coolant tank effectively retains the abrasive and impurities, thus guaranteeing a long coolant service life.
• Economical sanding due to simple and quick belt changes
• Perfect safety by means of belt protection box made of sheet steel or aluminum
• Available in various designs and belt widths to suit your needs
Scope of supply
- Horizontal to vertical adjustable surface grinding table
- Closed protective belt case out of sheet steel
- With built-in wet grinding device:
- With reinforced drive motor
- Large water catch tray
Technical Data
| Type | power (kW) | rpm | PS | Cutting speed (m/s) | abrasive belt (mm) | Suction nozzle diameter ø (mm) |
| BS 75 | 0,55 / 0,7 | 1450 / 2900 | 0,75 / 0,95 | 8/16 | 950 x 100 | 75 |
| BS 75 W | 1,1 | 1450 | 1,5 | 16 | 950 x 100 | -- |
| BS 200 | 1,8 / 2,2 | 1450 / 2900 | 2,5 / 3,0 | 10/20 | 1500 x 200 | 100 |
| BS 200 W | 2,0 / 2,4 | 1450 / 2900 | 2,7 / 3,2 | 10/20 | 1500 x 200 | -- |
| BS 300 | 3,0 | 1450 | 4,0 | 15 | 2000 x 300 | 150 |
| BS 300 W | 4,0 | 1450 | 5,5 | 15 | 2000 x 300 | -- |
| Attachment: | fixed support table with steel belt protection box (basic equipment) |
|---|---|
| Color: | light grey |
| Cutting speed: | 8/16 m/s |
| Grinding belt: | 950 x 100 mm |
| Machine design: | table model |
| Power: | 0.55 / 0.7 kW |
| Rotational speed: | 1450 / 2900 U/min |
accessories
adjustable angular stop
After logging in, the trade prices are visible.
detent
Adjustable 2 x 90° and is inserted into the T-slot of the AT tables.For the Rema double grinding machines DS and WS.
After logging in, the trade prices are visible.
